The 789 series ball valve, 2-piece body, male-male BSP connection, full bore, stainless steel, with padlockable handle, for chemical, pharmaceutical and petrochemical industries.
| Specification | Value |
|---|---|
| DN inches NPS | 1/4'' |
| Option certificate 3.1 | Yes |
| CE risk category | II Module D1 |
| Thread standard | ISO 7-1 R/ISO 228-1 |
| Tightness test standard | ISO 5208. Rate A |
| Stem sealing material | PTFE gland packing |
| Opening device | Handle |
| Application | Industry |
| Shaft/stem matérial | Stainless steel AISI 316 |
| Lockable | Yes |
| Torque (Nm) | 4 |
| DN | DN8 - 1/4'' |
| Face to Face (mm) | 720.0 |
| Fluid | Acids |
| Body material | Stainless steel CF8M (1.4408) |
| Number of ways | 2 |
| Bore | Full |
| ISO pad 5211 | No |
| Packing gland | Yes |
| PS (bar) | 63 |
| Connections | BSP MF |
| Seats | PTFE-Glass |
| Ball material | Stainless steel AISI 316 |
| TS max (°C) | 180 |
| TS min (°C) | -20 |
| Ball valve design | 2-piece body |
| Warranty period | 2 years |
| CE | Yes |
| Handle material | Stainless steel AISI 304 |
| Handle type | Blue lever |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP MF Stainless steel CF8M (1.4408) Full 2-piece body 1/4'' | 789002 | S1006400 |
€8.77
(excl. btw)
|
add to cart |
| BSP MF Stainless steel CF8M (1.4408) Full 2-piece body 3/8'' | 789003 | S1006401 |
€8.77
(excl. btw)
|
add to cart |
| BSP MF Stainless steel CF8M (1.4408) Full 2-piece body 1/2'' | 789004 | S1006402 |
€9.56
(excl. btw)
|
add to cart |
| BSP MF Stainless steel CF8M (1.4408) Full 2-piece body 3/4'' | 789005 | S1006403 |
€12.73
(excl. btw)
|
add to cart |
| BSP MF Stainless steel CF8M (1.4408) Full 2-piece body 1'' | 789006 | S1006404 |
€19.50
(excl. btw)
|
add to cart |
| BSP MF Stainless steel CF8M (1.4408) Full 2-piece body 1''1/4 | 789007 | S1006405 |
€28.64
(excl. btw)
|
add to cart |
| BSP MF Stainless steel CF8M (1.4408) Full 2-piece body 1''1/2 | 789008 | S1006406 |
€40.16
(excl. btw)
|
add to cart |
| BSP MF Stainless steel CF8M (1.4408) Full 2-piece body 2'' | 789009 | S1006407 |
€68.69
(excl. btw)
|
add to cart |
